SZC-1 Series load cell weighing sensor

Application

Price computing scales

Model

YZC-1B

YZC-1

Capacity (KG)

2,3,5,6,8,10,30,35,40,50,60,80

5,6,8,20,40,50

Rated Output                         mV/V

2.0±0.15

2.0±0.15

Accuracy class

C2

C3

Maximum number of verification intervals  nmax

Maximum load cell verification intervals    Vmin

Emax/5000

Emax/7500

Combine error                        %RO

≤±0.030

≤±0.020

Creep                          %RO/30min

0.003

0.002

Temperature effect on sensitivity      %RO/ °C

0.0016

Temperature effect on zero            %RO/°C

0.003

0.002

Zero balance                         %RO

±1.0

Input resistance                      Ω

402±6

1066±10

Output resistance                     Ω

350±3

1000±10

Insulation resistance                  MΩ

5000

Recommended excitation voltage         V

10~15

Compensated temperature range          °C

-10~+40

Operating temperature range             °C

-35~+80

Safe overload                        %RO

150

Ultimate overload                    %RO

200

Load cell material

Aluminium alloy

Platform size

350x350

Connecting cable

Φ4.2x350mm

Method of connecting wire

Read input(+),Black input(-),Green output(+),White
